Total area: 15m2
The optional aluminium tape available from the dropdown menu is 50mm wide and 50m long.
Folterm Uno can be used as: ceiling insulation in attics in residential buildings insulation of external and internal walls in residential buildings floor insulation (with the use of panel boards and raised floor) roof insulation insulation of pipes and tanks insulation of air conditioning installations The Folterm Uno screen also has windproof and vapour barrier features Building Metallised polyester film (MPET) Polyethylene bubble foil Metallised polyester film (MPET) Properties Unlike traditional thermal insulation materials such as mineral wool, the Folterm Uno thermal insulation screen protects the building against heat loss by using the effect of reflecting thermal energy (infrared radiation) from the reflective surface made of metallised polyester foil. The efficiency of reflection of thermal radiation reaches up to 90%, while heat losses by radiation account for approx. 75% of the total heat loss of a building. At the same time, the screen can absorb approx. 1% of thermal energy. Heat-insulating reflective screens are also characterised by a low emissivity coefficient. So we can see that we can significantly reduce the heat loss of the building by using a barrier for infrared radiation. The energy efficiency of a barrier made of a thermal insulation screen will be optimal if we ensure there are air gaps on each side of the screen. Existence of gaps, the thickness of which should be at least 20 mm improves the effect of the reflection of thermal radiation. Folterm Uno is made of foil, with air bubbles closed in a polyethylene shell. The foil is covered on both sides with layers of metalled foil – a highly effective reflective coating ensuring reflection of infrared radiation. The operation of Folterm Uno is based mainly on the principle of reflection of thermal radiation, therefore this type of thermal insulation is also called reflective. Folterm Uno, 3 mm thick, replaces approx. 5 cm of mineral wool. It is convenient and easy to assemble.
This product incorporates a reflective surface that minimises heat loss through the roof, ceiling, or walls. The outer and inner layers consist of aluminium polyethylene film, with the inner portion strengthened by a PP network for exceptional tensile strength. The top polyethylene layer is metallised to create a heat-reflective aluminium surface. This internally reinforced membrane not only shields the structure from water infiltration but also serves as a heat-absorbing layer.
Features:
Excellent stability, strength and cohesion
Specially designed to reduce heat loss
Highly tear resistant
Very lightweight and easy to cut (no special equipment required)
Multi layered aluminium
For use in Refurbishment & New Builds
Prevent ingress of water/moisture
Extremely economical and waste free
Ease of application
Cost effective
Thermally insulating properties – equivalent to 55mm Polystyrene Insulation
The reflection foil is designed for direct application in underfloor heating systems; under heating pipes and can easily be cut to fit any shaped areas. The foil reflects heat and deflects the cold temperature down to prevent heat loss to the sub floor and increase the system’s efficiency.
Applications:
Floors – under floor boards and between floor joists
Underfloor Heating – under underfloor heating pipes
Ceilings – between ceiling joists and under plasterboard
Roof – can be used in ventilated and non-ventilated roofs
Walls – in dry lined stud walls and against solid walls
Specs:
Length: 12.5
Width: 1.2m
Thickness: 3mm
Certification: This product is fully CPR Compliant, CE Approved
